Specification for the Mentor M550 DC Controller
- Power: 235kW
- Armature Current: 550A
- Model No.: M550
- Type: Digital DC Controller
- Phase: Three Phase
- Quadrant: 2Q
- Dimensions WxHxD: 450mm x 405mm x 280mm
Mentor 235kW Three Phase M550
This model is now obsolete View the Direct EquivalentLegacy Mentor II 2Q Three Phase Digital DC Controller Features
- Microprocessor Based Digital Drive
- Up to 750kW, 3 Phase, 200 to 660 VAC
- Regenerative and Non-regenerative Models
- RS485 Serial Communications
- Plug-in 32 bit application coprocessor card - MD29
-
Fieldbus -
- Interbus-S (MDIBS)
- Profibus-DP (MD24)
- DeviceNet (MD25)
- MentorSoft Windows based drive configuration tool
Technical specifications
Similarities with the Mentor II
- Same sizing as the Mentor II
- Same footprint as the Mentor II
- Same mounting brackets as the Mentor II
- Same power terminal locations
Retrofit Procedure
- Extract parameters / Program from the drive
- Disconnect power and control connections
- Undo and remove top bracket
- Lift out Mentor II
- Fit new Mentor MP onto existing bracket
- Reattach top bracket
- Reconnect power and control connections
- Parameterise
Product PDF's
Click the links below to view and download 235kW 550A 380/480VAC 2Q PDF's
